| Brand Name: | OEM |
| Model Number: | OEM |
| MOQ: | 1unit |
| Price: | Negotiable |
| Delivery Time: | 20days |
Grid tied residential home solar power system 1kw Residential Solar Power Systems
Description:
There are a number of steps to follow when planning to power your home with solar energy. After choosing
which option is best for you to use solar (see step 3), follow the steps afterward that apply to you. Your
solar energy installer and local utility company can provide more information on the exact steps you will
need to take to power your home with solar energy.
1. Investigate your home's energy efficiency
2. Assess your solar potential and any limitations
3. Assess your options for going solar
4. Estimate your solar electricity needs
5. Obtain bids and site assessments from contractors
6. Understand available financing and incentives
7. Work with your installer and utility to install the system and set up agreements
| 1.1KW Grid Tied Solar System Specification | ||
| SOLAR PANEL | ||
| Solar panel power Pm | 12*260WP | |
| Power allowance | ±3% | |
| Optimized working voltage Vm | 36.6V | |
| Optimized working current Im | 7.1A | |
| Open circuit voltage Voc | 45.1V | |
| Short circuit current Isc | 7.67A | |
| GRID TIED INVERTER | ||
| Inverter Input (DC) | ||
| Max. DC power | 3100W | |
| Max. DC voltage | 500V | |
| Max. input current | 8.8A | |
| Number of MPP trackers/Strings per MPP tracker | 1 1 | |
| MPPT voltage range (at rated power) | 120～425V | |
| Shutdown voltage/Start voltage | 70/120V | |
| Inverter Output (AC) | Inverter Output (AC) | |
| AC nominal power | 3000W | |
| Max. AC power | 1000W | |
| Max. AC current | 5.5A | |
| Nominal AC voltage / range | 230 / 180~270V | |
| AC grid frequency / range | 50 / 47~52Hz | |
| Power factor (cosφ) | 1 | |
| Total harmonic distortion (THDi)(at nominal power) | <3% | |
| Inverter Efficiency | Inverter Efficiency | |
| Max. efficiency | 96.60% | |
| Euro efficiency | 95.50% | |
| MPPT efficiency | 99.90% | |
| Inverter General data | ||
| Dimensions (W / H / D) | 285*385*145mm | |
| Weight [kg] | 15Kg | |
| Operating temperature range | -20～+60 (derating at 45 °C) | |
| Ingress protection | IP65 | |
| Topology | transformerless | |
| Internal consumption(night) | 0 | |
| Cooling concept | Convection | |
| Noise (typical) | <30 dB | |
| LCD display | Backlight, 16*2 Character LCD | |
| Communication port | RS232 | |
| SOLAR PANEL MOUNTING(Pitch roof ) | ||
| Rail | 2600mm*8pcs | |
| Hook | 24pcs | |
| Middle clamp | 20pcs | |
| End clamp | 8pcs | |
| Connect of rail | 4pcs | |
| Grounding lug (Optional) | 10pcs | |
| Earthing clips (Optional) | 10pcs | |
| ELERTRIC BOX (Optional) | AC/DC Circuit Breakers,Lighting arrestors, Electric meter | |
Work with Your Installer and Utility
If you decide to install a solar energy system, your installer should be able to help you complete the
necessary permitting and steps.
Your installer will determine the appropriate size for your system. The size will be based on your electricity
needs (determined in step 4) as well as the following:
The site's solar resource or available sunlight
The system's orientation and tilt
The system's efficiency at converting sunlight to electricity
Other electricity sources, like a utility, a wind turbine, or a fossil fuel generator.
Your installer will also ensure that all equipment is installed correctly and oriented and tilted in such a way
to maximize the daily and seasonal solar energy received and produced by your system.
Be sure you understand how billing and net metering will work, as well as any additional utility fees you will
need to pay.
