| Brand Name: | OEM |
| Model Number: | OEM |
| MOQ: | 1unit |
| Price: | Negotiable |
| Delivery Time: | 20days |
modern home solar power planet On-grid solar energy package Residential Solar Power Systems
Blank Grid-Tied PV System
Note: All numbers are retied, manufacturers’ specifications, or nominal unless otherwise specified.
Photovoltaics: Eighteen Kyocera KC200GT, 200W each at 26.3 Vmp, wired in two 9 module series strings
for 3,600W total at 236.7Vmp
Inverter: Aurora PVI-3600-US, 3,600W, 600VDC max. Input, 240VAC output.
KWH Meter: To utility grid
AC Disconnect
Fuses: Two, 60A
Lighting Arrestor
AC Service Entrance: To 120/240 VAC loads
| 1.1KW Grid Tied Solar System Specification | ||
| SOLAR PANEL | ||
| Solar panel power Pm | 6*190WP | |
| Power allowance | ±3% | |
| Optimized working voltage Vm | 36.6V | |
| Optimized working current Im | 5.19A | |
| Open circuit voltage Voc | 45.1V | |
| Short circuit current Isc | 5.57A | |
| GRID TIED INVERTER | ||
| Inverter Input (DC) | ||
| Max. DC power | 1100W | |
| Max. DC voltage | 500V | |
| Max. input current | 8.8A | |
| Number of MPP trackers/Strings per MPP tracker | 1 1 | |
| MPPT voltage range (at rated power) | 120～425V | |
| Shutdown voltage/Start voltage | 70/120V | |
| Inverter Output (AC) | Inverter Output (AC) | |
| AC nominal power | 1000W | |
| Max. AC power | 1000W | |
| Max. AC current | 5.5A | |
| Nominal AC voltage / range | 230 / 180~270V | |
| AC grid frequency / range | 50 / 47~52Hz | |
| Power factor (cosφ) | 1 | |
| Total harmonic distortion (THDi)(at nominal power) | <3% | |
| Inverter Efficiency | Inverter Efficiency | |
| Max. efficiency | 96.60% | |
| Euro efficiency | 95.50% | |
| MPPT efficiency | 99.90% | |
| Inverter General data | ||
| Dimensions (W / H / D) | 285*385*145mm | |
| Weight [kg] | 15Kg | |
| Operating temperature range | -20～+60 (derating at 45 °C) | |
| Ingress protection | IP65 | |
| Topology | transformerless | |
| Internal consumption(night) | 0 | |
| Cooling concept | Convection | |
| Noise (typical) | <30 dB | |
| LCD display | Backlight, 16*2 Character LCD | |
| Communication port | RS232 | |
| SOLAR PANEL MOUNTING(Pitch roof ) | ||
| Rail | 2600mm*4pcs | |
| Hook | 12pcs | |
| Middle clamp | 10pcs | |
| End clamp | 4pcs | |
| Connect of rail | 2pcs | |
| Grounding lug (Optional) | 5pcs | |
| Earthing clips (Optional) | 5pcs | |
| ELERTRIC BOX (Optional) | AC/DC Circuit Breakers,Lighting arrestors, Electric meter | |
Solar energy, solar air heating, solar cooking, solar pumping, solar power, solar hot woter, wind power, solar
pool heating,
others: heat energy, winter solar inssues, pure/true vs modified sine wave inverters, how to make solar
cells, insulation, how to find true south, shading/obstables, how to make a sun finder, how to square a solar
array frame, mini solar tower.
Stay energized even when the grid is down
When the grid is available, power produced by your solar system is used by the home and excess energy is
sent into the utility grid. In the event of a power outage the backup inverter will automatically turn on to
power critical appliances such as the fridge/freezer, lights, well pump, computer, phone and more. The
combination of solar energy and battery storage works seamlessly to provide power to essential appliances
during an outage, working similar to an off-grid system. A backup gas generator could be incorporated for an
extra degree of independence to protect against long-term power outages.
video
video
video
video
|
|
