| Brand Name: | OLLIN PV |
| Model Number: | OEM |
| MOQ: | 1 piece/unit |
| Price: | negotiation |
| Delivery Time: | 20DAYS |
Small solar panel for science projects
Power small motors or other loads
High-efficiency encapsulated solar panel
Charge 2 - 1.2V batteries, AA, AAA
Product description
High Efficiency Miniature Solar Cell, can easily be arranged for larger load applications including higher
voltage and current loads. Miniature compact size with solid attractive casing.
Specifications :Monocrystalline Solar Cell •
Efficiency: 17.0% •
Color: Blue •
Peak Voltage (Vmp): 3.0V •
Open Circuit Voltage (Voc): 3.6V •
Peak Current (Imp): 100mA •
Short Circuit Current (Isc): 110mA •
Dimensions:80mm diameter
| Item No. | Max Power | Rated Voltage | Output Voltage | Dimension | Net Weight |
| 0.5V100MA | 0.05W | 0.5VDC | 53x18x3mm | 0.003kg | |
| 1V85MA | 0.085W | 1VDC | 30x25x3mm | 0.0022kg | |
| 1.5V400MA | 0.65W | 1.5VDC | Charge for 1.2V Battery | 80x60x3mm | 0.018kg |
| 2V130MA | 0.26W | 2VDC | 54x54x3mm | 0.009kg | |
| 2V50MA | 0.1W | 50x34x3mm | 0.008kg | ||
| 3V120MA | 0.36W | 3VDC | 60x55x3mm | 0.011kg | |
| 5V30MA | 0.15W | 5-5.5VDC | Charge for 3.6V-3.7V Battery | 53x30x3mm | 0.005kg |
| 5V60MA | 0.3W | 68x36x3mm | 0.01kg | ||
| 5V150MA | 0.75W | 99x69x3mm | 0.02kg | ||
| 5.5V50MA | 80x35x3mm | 0.01kg | |||
| 5.5V60MA | 0.3W | 100x28x3mm | 0.01kg | ||
| 5.5V100MA | 0.55W | 84.5x55.5x3mm | 0.018kg | ||
| 5.5V120MA | 0.66W | 80x60x3mm | 0.02kg | ||
| 6.5V90MA | 0.6W | 6-6.5VDC | 120x70x3mm | 0.03kg | |
| 6V100MA | 0.6W | 120x38x3mm | 0.016kg | ||
| 6V330MA | 2W | 136x110x3mm | 0.06kg | ||
| 6V500MA | 3W | 145x145x3mm | 0.07kg | ||
| 6V580MA | 3.5W | 135x165x3mm | 0.077kg | ||
| 6V750MA | 4.5W | 145x145x3mm | 0.07kg | ||
| 8V150MA | 1.2W | 8VDC | Charge for 6V Battery | 145x95x3mm | 0.05kg |
| 12V250MA | 3W | 12VDC | Charge for 8V Battery | 145x145x3mm | 0.07kg |
| 18V190MA | 3.5W | 18VDC | Charge for 12V Battery | 165x135x3mm | 0.082kg |
| 18V200MA | 4.2W | 200x130x3mm | 0.109kg |
SOLAR PV SYSTEM
Solar PV system includes different components that should be selected according to your system type,
site location and applications. The major components for solsr PV system are solar charge controller,
inverter, battery bank, auxiliary energy sources and loads (appliances).
PV module - converts sunlight into DC electricity.
Solar charge controller - regulates the voltage and current coming from the PV panels going to battery
and prevents battery overcharging and prolongs the battery life.
Inverter - converts DC output of PV panels or wind turbine into a clean AC current for AC appliances
or fed back into grid line.Battery - stores energy for supplying to electrical appliances when there is a
demand.Load - is electrical appliances that connected to solar PV system such as lights, radio, TV,
computer, refrigerator, etc.
Auxiliary energy sources - is diesel generator or other renewable energy sources.
|
|
