| Brand Name: | OLLIN PV |
| Model Number: | OL-36M-30 |
| MOQ: | 1 piece/unit |
| Price: | Negotiable |
| Delivery Time: | 20DAYS |
1) 3 times inspection from material to goods,to low down the defective rate to the minimum,including IV
test ,EL test.
2) All of our solar panel product haves passed the ISO14001,ISO9001,ISO18001,CE,TUV approve.
3) We csn provide solar panel from 5w to 360w,giving you customized service.
4) Sunket using advanced automatic equipment to control product quality.
Electrical Characteristics
| ITEM NO | 30W/18V |
| MONO or POLY | poly |
| Maximum power (Wp) | 30wp |
| Maximum power voltage (V) | 18 |
| Maximum power current (A) | 1.66 |
| Open circuit voltage (V) | 21.6 |
| Short circuit current (A) | 1.79 |
| Number of cells (Pcs) | 36 |
| Size of module (mm) | 650*340*23 |
| Brand Name of Solar Cells | HT |
| Maximum system voltage (V) | 715 |
| Temperature coefficients of Isc (%) | 0.065+/-0.015%/°C |
| Temperature coefficients of Voc (%) | -(2.23+/-0.1)mv/ °C |
| Temperature coefficients of Pm (%) | -(0.5+-0.05)/ °C |
| Temperature coefficients of Im (%) | +0.1/ °C |
| Temperature coefficients of Vm (%) | -0.38/ °C |
| Temperature Range | -40°C~+85°C |
| Tolerance Wattage (e.g. +/-5%) | +/-5% |
| Surface Maximum Load Capacity | 60m/s(200kg/sq.m) |
| Allowable Hail Load | steel ball fall down from 1m height |
| Weight per piece (kg) | 1.1 |
| Length of Cables (mm) | 1m |
| Cell Efficiency (%) | more than13% |
| Module Efficiency (%) | more than 8% |
| Output tolerance (%) | +/-5% |
| Frame (Material, Corners, etc.) | Aluminum |
| Standard Test Conditions | AM1.5 100mw/cm2 25°C |
| Warranty | 2 years product warranty and 25years 80% of power |
| FF (%) | 75% |
| Packing | 10PCS/ CTN |
| Unit Price |
Detailed Images
Name: Glass
Anti-reflective coating to increase the module efficiency up to 2%.
Light transmittance improvement about 3%.
Self-cleaning function
Name: Back Sheet
Low moisture permeability against snail trail defect.
Excellent electric insulation for high system voltage up to1500v.
Outstanding weatherproof permance.
Name:Solar Cell
High power efficiency.
Stable performance under weak light conditions.
PID free treatment upon request.
Name:Frame
Strong mechanical load resistance up to 5400 pa.
Anodic oxidation layer resistant to chemical corrosion.
Silver and black color optional.
Application
1. Countryside and remote areas
2. Home and vacation villa
3. Railway signal
4. Beacon and beacon lights
5. Small-scale desalination
6. Emergency System
7. Street lighting system
8. Emergency communication system
9. Vehicle and ship systems
10. Cathodic protection
11. Wind-Light complementary power supply system
12. Water quality and environmental data monitoring system
